Since the release of the original SEC Millenium 22 years ago, our engineers have designed and implemented enhanced optical absorption integrity, lower power consumption and developed software algorithms for our other infrared family of gas detectors and analyzers.  All of this knowledge, experience and features have been incorporated into the SEC Millenium Hawk.


SEC Signature Process Gas Analyzer

  • Gas analyzer with optical gas detector
Click image to enlarge


The SEC Signature Process Gas Analyzer is a self-contained optical gas detector designed for non-intrusive continuous monitoring of process gases.  These process gas analyzers operate in anaerobic atmospheres.  The Signature Process infrared gas analyzer is unaffected by humidity and pressure.  The infrared optical system is self-compensating (patented) for most aging, environmental, and contamination effects resulting in excellent measurement integrity.  No mirrors or reflecting surfaces are used in this device.  Anodized aluminum surfaces of the optical chambers are heated to discourage condensation. These gas analyzers are explosion proof and low cost.  The SEC optical gas detector continually does self-diagnostics to ensure reliable protection for your personnel and equipment. The SEC Signature process gas analyzers are used in the medical field where equipment is being sterilized.  Other applications for the SEC Signature optical gas detector is laboratories, clean rooms or the petrochemical industry.  Calibration can be done easily by using the SEC PC IR Link.  The SEC Signature process gas analyzers meet applicable FDA standards, while eliminating weeklong manufacture-to-market delay.


  • Infrared Sensing Technology
  • Explosion Proof and low cost
  • Patented Self Compensating Optical Bench
  • Designed for non-extractive sampling
  • Simple calibration
  • Unaffected by humidity and pressure
  • Fast Response Time
  • Linear outputs
  • Continual Self-diagnostics
  • Independent pressure compensation input

 *Please select the quantity for each item you wish to order and click the 'Add To Cart' button below.

  • Medical
  • Laboratories
  • Clean Room
  • Petrochemical

Part Number:

  • EtO:  1420597
  • CO2: 1420848
  • Hydrocarbon: 1421014

Range (adjustable):

  • EtO: 0-2000 mg/liter
  • CO2: 0-100% VOL
  • Hydrocarbon:  0-100% VOL

Output (analog):

  • 4-20mA (Source Type)

Digital Output:

  • Interactive P.C. link


  • ± 5% of reading or ± 3% full scale (whichever is greater)


  • ±2%


  • Anodized Aluminum and Sapphire

Mechanical Connection:

  • ¾” NPT

Operating Range:

  • 18 to 32 VDC

Power Consumption:

  • 6 Watts Max

Max Current Draw (at 24VDC):

  • Average: 250mA   Peak:  450mA

Wire Connections:

  • Red wire (+ 24 VDC)
  • Black wire (D.C. common)
  • Blue wire (4-20 mA output signal)
  • White wire (Calibration/digital interface)


  • CSA, CE


  • Class 1, Div 1, Groups B, C, D (-40º to 50ºC)


  • 0-99% (Non-condensing)

Operating Temperature:

  • 0-65º C

Operating Pressure:

  • 1 PSIA – 55 PSIA

Installation Category:

  • Cat 1, Pollution Degree 2


  • 2 lbs (0.92 Kg.)
